Solis 80kW Three Phase High Voltage Hybrid Solar Inverter
The Solis S6 Three Phase 80kW High Voltage Hybrid Solar Inverter is a powerful commercial and industrial energy storage solution designed for large-scale solar installations. Combining advanced photovoltaic generation, battery storage integration and intelligent energy management, this inverter provides exceptional flexibility for grid-tied, hybrid and backup power applications.
With support for up to 160kW of PV input, 10 independent MPPTs and dual high-voltage battery connections, the Solis 80kW Hybrid Inverter is engineered to maximise energy production while delivering reliable backup power and energy storage functionality. It is ideal for factories, warehouses, agricultural facilities, office parks, shopping centres and commercial buildings seeking greater energy independence and lower electricity costs.
Built for Commercial and Industrial Energy Storage
The Solis Solarator Series was developed specifically for demanding commercial energy storage applications. The inverter supports both DC-coupled and AC-coupled solar systems, allowing flexible deployment for new installations and retrofit projects.
Key Features
- 80kW three-phase hybrid inverter
- Supports up to 160kW PV array capacity
- 10 MPPT trackers
- 20 maximum string inputs
- PV input voltage up to 1000V
- MPPT operating range from 150V to 950V
- Dual high-voltage battery ports
- Battery voltage range from 300V to 950V
- 200A battery charge and discharge capability
- Less than 10ms backup switching time
- Generator integration support
- AC and DC coupling support
- Smart load management functionality
- Remote monitoring and firmware updates
- IP66 weather protection rating
Advanced MPPT Performance
The inverter incorporates 10 independent MPPT trackers, each capable of handling high-current solar modules. This design enables maximum energy harvesting across complex rooftop layouts, multiple roof orientations and large-scale ground-mounted solar systems.
Reliable Backup Power Capability
With UPS-grade transfer times of under 10 milliseconds, the inverter can supply critical loads with minimal interruption during grid failures. The inverter also delivers enhanced overload performance, making it suitable for applications with motor-driven equipment, pumps and inductive loads.
High Voltage Battery Compatibility
The Solis 80kW Hybrid Inverter supports high-voltage lithium battery systems operating between 300V and 950V. Dual battery connections provide greater design flexibility and support larger energy storage installations.
Scalable for Large Installations
The inverter supports parallel operation for large commercial projects. Multiple units can be combined to increase system capacity and backup power performance, making the platform suitable for growing energy requirements.
Smart Monitoring and Control
The included communication platform supports remote monitoring, diagnostics and firmware updates through Solis monitoring platforms. Installers and system owners can monitor performance, battery status and energy production from anywhere.
Applications
- Commercial solar installations
- Industrial facilities
- Warehouses
- Shopping centres
- Office parks
- Agricultural operations
- Manufacturing facilities
- Battery energy storage systems
- Hybrid solar systems
- Backup power installations
Technical Specifications
- Model: S6-EH3P80K-NV-YD-H
- Rated Output Power: 80kW
- Maximum PV Input Power: 160kW
- Maximum PV Input Voltage: 1000V
- MPPT Voltage Range: 150V – 950V
- Number of MPPTs: 10
- Maximum Strings: 20
- Maximum PV Input Current: 10 x 42A
- Maximum Short Circuit Current: 10 x 60A
- Battery Type: Lithium-ion
- Battery Voltage Range: 300V – 950V
- Maximum Charge Current: 200A
- Maximum Discharge Current: 200A
- Battery Ports: 2
- Maximum Efficiency: 97.6%
- European Efficiency: 97.2%
- Backup Switch Time: Less than 10ms
- Ingress Protection: IP66
- Cooling: Intelligent Fan Cooling
- Dimensions: 1174 x 814 x 400mm
- Weight: 170kg
- Communication: CAN, RS485, Ethernet
- Optional Communication: WiFi, LAN, Cellular
- Display: 7-inch LCD Touch Interface
- Warranty: 5 Years Standard
NRS097 and CoCT Approved
The Solis 80kW Three Phase High Voltage Hybrid Solar Inverter is approved for use in South Africa and complies with NRS097 requirements, including City of Cape Town approval where applicable.
Why Buy From JC Solar Panels?
JC Solar Panels supplies professional commercial solar equipment, battery storage systems and hybrid inverters for projects across South Africa. Our team can assist with system design, battery compatibility, installation support and nationwide delivery for commercial and industrial solar projects.
