Astronergy ASTRO N5s 480W Solar Panel

Astronergy ASTRO N5s 480W N-Type TOPCon Solar Panel

Astronergy 480W solar panel overview for South Africa

The Astronergy ASTRO N5s 480W N-Type TOPCon solar panel is a high-performance monocrystalline module built for strong energy yield, long lifespan, and stable output in real-world conditions. With up to 22.2% module efficiency, the Astronergy 480W solar panel is an excellent choice for homes, businesses, and larger PV projects where roof space and long-term performance matter.

This N-Type TOPCon 4.0 solar panel uses advanced cell technology, an SMBB (Super Multi-Busbar) design for improved current collection, and double-layer high-transmittance glass to support reliable performance and durability over time.

Why choose an Astronergy N-Type TOPCon solar panel

Key benefits of the Astronergy ASTRO N5s 480W module

Key benefits: High power output (480W) • High efficiency (22.2%) • Better temperature performance with low power temperature coefficient (-0.29%/°C) • Power sorting tolerance (0 ~ +3%) • Strong mechanical load capability (5400Pa front / 2400Pa rear) • Long-term reliability with low degradation.

Applications for the Astronergy 480W solar panel

The Astronergy ASTRO N5s 480W N-Type TOPCon solar panel is suitable for:

Applications: Residential rooftop solar systems

• Commercial and industrial PV installations

• Grid-tied solar systems

• Hybrid solar systems

• Off-grid solar systems

• Utility-scale solar farms

Electrical specifications for Astronergy ASTRO N5s 480W solar panel

Electrical specifications (STC) – Astronergy ASTRO N5s 480W

Rated Power (Pmax): 480 W
Module Efficiency: 22.2%
Voltage at Pmax (Vmpp): 36.52 V
Current at Pmax (Impp): 13.14 A
Open Circuit Voltage (Voc): 43.46 V
Short Circuit Current (Isc): 13.91 A
Power Tolerance: 0 ~ +3%

Electrical specifications (NMOT) – Astronergy ASTRO N5s 480W

Power at NMOT: 361.0 W
Voltage at Pmax: 34.37 V
Current at Pmax: 10.50 A
Open Circuit Voltage (Voc): 41.28 V
Short Circuit Current (Isc): 11.23 A

Temperature ratings for Astronergy N-Type TOPCon 480W solar panel

Temperature Coefficient (Pmax): -0.29% / °C
Temperature Coefficient (Voc): -0.25% / °C
Temperature Coefficient (Isc): +0.043% / °C
Nominal Operating Module Temperature (NMOT): 41 ± 2 °C

Mechanical specifications for Astronergy ASTRO N5s 480W module

Dimensions: 1908 × 1134 × 30 mm
Weight: 23 kg
Cell Type: N-Type monocrystalline
Number of Cells: 120 (6 × 20)
Frame: Anodised aluminium (black or silver)
Glass: 1.6 mm + 1.6 mm tempered glass
Connector Type: PV-KST4-EVO2A / Stäubli compatible
Cable Length: Portrait (+350 mm / −250 mm)
Junction Box Rating: IP68
Maximum System Voltage: 1500 V DC
Maximum Series Fuse Rating: 25 A

Mechanical load rating – Astronergy ASTRO N5s 480W

Front Load: 5400 Pa
Rear Load: 2400 Pa

Warranty and degradation for Astronergy ASTRO N5s 480W solar panel

Product Warranty: 15 Years
Linear Power Output Warranty: 30 Years
First-year degradation: ≤ 1.0%
Annual degradation (Years 2–30): ≤ 0.4%

Logistics and packaging for Astronergy 480W solar panels

Panels per box: 36
Panels per 40HQ container: 864
Approximate container packing weight: 875 kg
