Jinko 555 Watt Mono Solar Panel – JKM-555M-72HL4-V

Jinko 555 Watt Mono Solar Panel

Model: JKM-555M-72HL4-V
Type: Mono-Facial Module
Power Output: 555W
Cell Count: 144 Cells
Frame: Anodized Aluminium Alloy

Key Features:

• Positive Power Tolerance: 0 to 3%
• Multi Busbar Technology: Enhances light trapping and current collection, improving module power output and reliability.
• Reduced Hot Spot Loss: Provides a better temperature coefficient, ensuring optimal performance.
• Longer Life-Time Power Yield: Durable and reliable over the long term.
• Resistance: High resistance against salt mist and ammonia, ideal for harsh environments.
• Cell Type: P-Type Mono-Crystalline
• Junction Box: IP68 rated

Performance:

• Maximum Power (STC): 555W
• Maximum Power (NOCT): 413W
• Maximum Voltage (STC): 40.99V
• Maximum Voltage (NOCT): 38.59V
• Maximum Current (STC): 13.54A
• Maximum Current (NOCT): 10.70A
• Open-Circuit Voltage (STC): 49.72V
• Open-Circuit Voltage (NOCT): 46.93V
• Short-Circuit Current (STC): 14.12A
• Short-Circuit Current (NOCT): 11.40A
• Module Efficiency (STC): 21.48%
• Operating Temperature: -40°C to 85°C
• Maximum System Voltage: 1000/1500VDC (IEC)
• Maximum Series Fuse: 25A

Physical Specifications:

• Weight: 28.9 kg
• Dimensions (L x W x D): 2278 x 1134 x 35 mm

Additional Information:

• Mounting Kits & Accessories: Not included, sold separately.
• Warranty: 12-Year Limited Product Warranty. Terms & Conditions Apply.

Refer to the brochure for detailed product specifications. This panel is designed to provide reliable and efficient solar energy for various applications, ensuring high performance and longevity.
