Felicity Solar 8kW 48V Off-Grid Inverter

Felicity Solar 8kW 48V Off-Grid Inverter – IVEM8048

The Felicity Solar IVEM8048 is a high-performance 8kW off-grid inverter designed for demanding residential, agricultural and commercial off-grid applications. It delivers pure sine wave output, advanced lithium battery integration and dual MPPT solar charging, ensuring reliable power delivery even in harsh operating environments.

System Overview

This inverter operates on a 48V battery system and supports both solar and generator input. With dual AC outputs and configurable load priority, it allows critical and non-critical loads to be managed independently for optimal energy efficiency.

Key Features

• 8kW / 8000VA pure sine wave output
• 48V battery system compatibility
• Dual MPPT solar charge controller (2 PV strings)
• Built-in WiFi for remote monitoring via mobile app
• Supports lithium, AGM and gel batteries
• Parallel operation up to 6 units
• Dual AC output with programmable scheduling
• Operates with or without batteries
• Cold start and auto-restart functionality
• Advanced protection against overload, overheating and short circuits

Electrical Specifications

• Rated Power: 8000W / 8000VA
• Battery Voltage: 48V (56.4V nominal)
• AC Output: 230V, 50Hz (pure sine wave)
• PV Input Voltage Range: 100V – 450V DC
• Maximum PV Power: 10,000W (5,000W per MPPT)
• Maximum Charging Current: 150A
• Efficiency: Up to 94.5%

Battery & Monitoring Compatibility

The IVEM8048 supports intelligent BMS communication with Felicity lithium batteries via RS485, enabling real-time SOC monitoring, charge control and battery protection. WiFi monitoring allows users and installers to track system performance remotely.

Physical Specifications

• Net Weight: 23.7 kg
• Product Dimensions (W × H × D): 607 × 406 × 141 mm
• Package Dimensions: 712 × 582 × 259 mm

Ideal Applications

• Off-grid homes and lodges
• Farms and agricultural installations
• Workshops and small businesses
• Backup power systems with battery storage
